YoloLiv YoloBox Pro 8'' LCD All-in-one Portable Multi-Cam Live Streaming Studio Monitor Encoder Recorder Switcher

YoloBox Pro is a full HD live broadcast device integrating encoder, switcher, monitor and recorder, with built-in battery and native support for 4G LTE, WiFi, Ethernet. Perfect for Worship, Weddings/Funerals, Sport, Events, Corporate, Education, Retail Business and Much More.

New Firmware 1.6.0 Update

As of the 1.6.0 update:

• Web URL Overlay: you can create professional-grade live graphics in minutes on any production, or enter an URL of a customized scoreboard generated from a live graphics platform like singular.live or flexyscore.net for professional sports events.
• Auto-Switching: the auto-switching feature allows you to automatically rotate between up to 6 video sources, including camera angles (HDMI 1, HDMI 2, HDMI 3, USB Type-C, and USB Type-A), SD card (videos and PDF), multi-views (PIP, Side by Side, Split View, News Layout, and Triple), and live stream (as video source). This feature is especially useful if you are running a production by yourself, or if you want to have continuous camera switching
• USB Webcam Out: USB webcam out feature was released a couple of weeks before, and it's optimized in this version. You can now output both video and audio to your computer for meetings on Zoom, Skype, Teams, and more.
• Additional Multi-View Templates: a Multiview is an on-screen asset that allows you to combine multiple sources, such as camera angles, USB inputs, and SD card assets (videos and PDF) into a single view. We released 2 new multiview types, News Layout and Triple.
• SD card video playback timing.
• Scheduling a live stream within one year.
• Option to adjust transparency for countdown timer overlay.
• Save all graphic overlays while creating a new live stream.
• UI redesigned for the "Account" screen.

Key Features

• Touch control without a computer
• 8" LCD display with 400 cd/m² brightness
• Built-in simultaneoulsy streaming to up to 3 destinations
• HDCP compliant
• Stream via Ethernet, Wi-Fi, LTE 4G
• Live switch up to 8 sources
• 3 x HDMI inputs, 1 x USB video input, 1 x SD card slot, 1 x HDMI output
• One USB Type-C charging input
• Mic and Line audio input, 1 x audio output
• Ability to input PDF
• Add logos/comments to the stream
• Import pictures/videos from SD card
• Records internally to SD card up to 128GB
• Direct integration with YouTube/Facebook/RTMP(s)
• Supports up to 1080p60 video

Touchscreen Control

The YoloBox Pro provides you with a large touchscreen interface for easy streaming and control.

Functions

The device works as a switcher, with a variety of picture-in-picture templates as well as graphic layers. It has a built-in encoder that allows for live streaming, and it can record to optional SD cards up to 128GB.

Overlays

• You can brand your live stream by adding logos/watermarks/rolling captions
• Customized PiP options, including Interview mode, allow you to bring a unique look and feel to your stream
• Engage with your audience in real time via feature comment overlays
• The customizable scoreboard feature displays a real-time-controlled scoreboard for professional looking results
• Built-in lower-thirds templates can be edited or you can add your own

Internet

• You can connect to the internet using the integrated RJ45 (Ethernet) port, Wi-Fi, and via cell service using an optional SIM card.

Simultaneous Streaming

• YoloBox Pro will first push your feed to the YoloLIV platform, from where it automatically forward your feed to a maximum of 3 destinations simultaneously.

Streaming Platforms

• Major steaming platforms such as Facebook live, YouTube, and twitch as well as YoloLIV are supported.
• RTMP protocols allow you to stream to custom RTMP destinations including YouTube.

SD Card Input

• Roll in pre-recorded videos for intro, countdown, B-roll, or special segments from an SD media card.

PDF

• You can load a PDF as a local source to your YoloBox.

Battery Life

• The internal 10,000mAh battery can power your YoloBox Pro for approximately 3 hours. The YoloBox Pro charges via a USB Type-C input, which is used for power only.

SPECIFICATIONS
