Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)

Write a Review
SKU:
HOLPYRO-S
UPC:
6976068115496
Shipping:
Calculated at Checkout
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
  • Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System (1 TX + 1 RX)
MSRP: $1,179.00
$1,109.00
— You save $70.00

Description

Add 4K30 wireless video transmission to your production using the versatile Hollyland Pyro S 4K HDMI/SDI Wireless Video Transmission System. The system includes a wireless transmitter, a wireless receiver, seven antennas, a USB-C adapter, a DC power adapter, and an adjustable shoe adapter mount. The transmitter provides HDMI and SDI inputs and features extremely low 50 ms latency that accepts line-of-sight transmission from up to 1300' away to the included receiver. When using broadcast mode using up to four receivers and two mobile devices, the system supports up to 650' away. The receiver outputs to HDMI and SDI.

Each Pyro S unit is equipped with a USB-C port that can power the unit and also supports plug-and-play UVC operation, so it can seamlessly plug into a computer and utilize the wireless video for streaming and conferencing applications. A built-in frequency scanner allows you to select the clearest frequency for your transmission and features a bright LCD for configuration. In addition to the multifunction USB-C port, each unit can be powered using a separately available locking DC power adapter or an L-series type battery using an optional battery plate.

  • 1 Transmitter & 4 Receivers
  • 1,300ft (400m)
LOS Range
  • 0.06s Low Latency
  • 2.4GHz & 5GHz Dual Band
  • Auto Frequency
Hopping
  • HDMI & SDI
  • Multiple Power Supply Options
  • UVC & RTMP Streaming
  • 4K30 Transmission
  • Ready Out of the Box
Long Distance, High Quality
The Pyro S Wi-Fi broadcast technology enables one transmitter to connect to four receivers with stable signals, offering more flexibility when additional monitoring needs emerge on set. When Broadcast mode is activated, the transmitter can transmit signals to at most four receivers, and the line-of-sight range reaches 650'. When Broadcast mode is deactivated, the transmitter can transmit signals to at most two receivers and two mobile devices, and the line-of-sight range extends up to 1300'.

Strong Signal Strength
At a stable transmission range of up to 1300', the Pyro S features latency as low as 50ms. Compared to the Mars series, whose transmission range extends at the cost of image quality and latency, the Pyro S excels with increased transmission distance while preserving video quality and minimizing latency. The transmitter/receiver combo also provides two modes for users to tip the balance between image quality and latency, with HD mode for better image quality with bitrate at up to 12 Mb/s and Smooth mode for a dynamic change in latency.

Crisp and Sharp Images
With up to 4K30 transmission capabilities via HDMI and 1080p60 via SDI, the Pyro S transmits images with superior clarity, detail, and realism, making it a great choice for professional applications like broadcast and filmmaking.

USB Video Class
UVC allows seamless compatibility with a wide range of devices, such as computers, without requiring additional drivers or software installations. This plug-and-play feature simplifies setup and operation, making it convenient for users in various scenarios, such as live streaming and video conferencing.

RTMP
Input your wireless key and connect a network card to stream video directly to live platforms like Zoom, YouTube, Twitch, and TikTok.

Smart Channel Scan
Upon startup, Pyro S automatically chooses a high-quality frequency channel, optimizing the user experience from the outset. Additionally, users can activate the smart channel scan function on the receiver to view real-time feedback on the frequency status, thus ensuring an uninterrupted and reliable experience.

Easy Setup
The Pyro S supports preset grouping and pairing, eliminating the need for users to repetitively and manually set up the transmitter and receivers.

Continuous Power, Multiple Options
In addition to DC input and NP-F batteries, the Pyro S also supports a USB-C power supply (5-12V). A USB power supply option provides convenience, especially when using stabilizers, as it eliminates the need for larger NP-F batteries, reducing overall weight and enhancing maneuverability.

 SPECIFICATION

Transmitter:

Port DC Input: 2.0mm Core Socket
HDMI Input: HDMI 1.4b
SDI Input: 3G SDI
USB-C: USB 2.0
OTG Antenna: SMA Male
Power Supply Battery Voltage Range: 6.8 - 8.4V
DC Voltage Range: 6 - 16V
Power Consumption < 11W
Net Weight 207g
Dimensions  L × W × H: 112 × 71.2 × 34.1mm (4.4 × 2.8 × 1.3in.)
Input/Output Format HDMI Input

720p50/59.94/60
1080i50/59.94/60
1080p23.98/24/25/29.97/30
1080p50/59.94/60
3840*2160 30/25/24/29.97/23.98

SDI Input
1080p60/59.94/50

1080i60/59.94/50

1080p30/29.97/25/24/23.98

720p60/59.94/50

1080psf23.98/24 1080psf25/29.97/30
Operating Frequency 5 GHz Frequency Band

5.150 - 5.250 GHz

5.250 - 5.350 GHz

5.470 - 5.725 GHz

5.725 - 5.850 GHz


2.4 GHz Frequency Band

2.412 - 2.484 GHz
Transmit Power < 23 dBm
Receiver Sensitivity /
Latency as low as 50ms
Bandwidth 20 MHz (Broadcast: 40 MHz)
Working Temperature -10 - 45℃ (working)
-40 - 60℃ (storage)

 Receiver:

Port DC Input: 2.0mm Core Socket
HDMI Input: HDMI 1.4b
SDI Input: 3G SDI
USB-C: USB 2.0 OTG
Antenna: SMA Male
Power Supply Battery Voltage Range: 6.8 - 8.4V
DC Voltage Range: 6 - 16V
Power Consumption < 8W
Net Weight 207g
Dimensions  L × W × H: 112 × 71.2 × 34.1mm (4.4 × 2.8 × 1.3in.)
Input/Output Format HDMI Input

720p50/59.94/60
1080i50/59.94/60
1080p23.98/24/25/29.97/30
1080p50/59.94/60
3840*2160 30/25/24/29.97/23.98

SDI Input
1080p60/59.94/50

1080i60/59.94/50

1080p30/29.97/25/24/23.98

720p60/59.94/50

1080i50/59.94/60
Operating Frequency 5 GHz Frequency Band

5.150 - 5.250 GHz

5.250 - 5.350 GHz

5.470 - 5.725 GHz

5.725 - 5.850 GHz


2.4 GHz Frequency Band

2.412 - 2.484 GHz
Transmit Power /
Receiver Sensitivity -85 dBm (Broadcast: -80 dBm)
Latency as low as 50ms
Bandwidth 20 MHz (Broadcast: 40 MHz)
Working Temperature -10 - 45℃ (working)
-40 - 60℃ (storage)



PACKAGE INCLUDES

  • 1 x Hollyland Pyro S 4K HDMI / SDI Wireless Video Transmitter
  • 1 x Hollyland Pyro S 4K HDMI / SDI  Wireless Video  Receiver
  • 7 x Paddle Antenna (2.4/5 GHz)
  • 1 x Rotatable Cold Shoe Mount
  • 1 x USB-C OTG Adapter
  • 1 x AC Power Adapter
