Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)

Write a Review

Take a Further 5% on Super Value Lighting Kits

Use Discount Code : Superfurther5

SKU:
FEEW1000H
UPC:
FEEW1000H
Shipping:
Calculated at Checkout
On Sale
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
  • Feelworld W1000H HDMI Wireless Video Transmission System (1 TX + 1 RX)
MSRP: $769.00
Now: $599.00
Was: $699.00
— You save $170.00
  • Fotolux NP-F770 Li-on Replacement Battery for Sony
  • Nicefoto NP-F970 Li-on Replacement Battery for Sony
  • Fotolux LCD Display USB Dual-slot NP Li-on Battery Charger for LED Light , LCD Monitor
  • Nitecore USN3 PRO USB Dual-slot Battery Charger for Sony NP-FM500H ,NP-F730 , NP-F750 , NP-F770 , NP-F970 , NP-F550

Description

FEELWORLD W1000H TX/RX set is a real-time wireless video transmission system integrated with intercom and live streaming. With 8Mbps high data rate, dual HDMI ports and other features built for professional filmmaking, the W1000H empowering filmmakers, crews, and content creators everywhere.

  • Dual HDMI signal interface, connect more devices
  • More than 1000ft transmission range with 0.08S ultra-low latency
  • Up to 1080P@60Hz, provide high quality image
  • Wireless full-duplex talkback, real-time intercom between the director  and the photographer
  • With type-C to Ethernet adapter accessory, achieve live streaming
  • The transmitter can be switched as a receiver at will
  • One TX to multiple RX, monitoring for everyone on set
  • Real-time APP monitoring for Android/iOS system
  • 13 frequency channels, AUTO channel scan

Full Duplex Wireless Communication
Meet the real-time intercom between the director and the photographer
The one of highlights for W1000H its full duplex intercom, just connect to headphone, enable communication between the director and the photographer, save your time and costs to set an extra intercom system.

Direct Video for Live Stream , Supports static IP and route IP
With the Type-C to Ethernet adapter accessory, video feed straight out of RX (the receiver) will be used for live streaming on OBS, VLC on our personal computer without further encryption and decryption via a video capture device.

Note: The Type-C to Ethernet adapter is optional

Compact and Lightweight
The W1000H is compact, lightweight, and small enough to mount anywhere. Both at the bottom of transmitter and receiver come with a single ¼”-20 mounting point for mounting camera arms, cold shoes, etc.

1000FT Transmission Range with 0.08S Low Latency
The W1000H has more than 1000ft hassle-free and reliable range for wireless video and audio transmission; 0.08S achievable latency for real-time monitoring that enables.

Dual HDMI Ports, Connect More Device
The transmitter with HDMI input and output, can output video a small monitor on the camera, allow the cameraman to clearly see the shots. The receiver with two HDMI outputs, which support simultaneous output the video.

One Device Dual Uses
More flexible and costs-effective
The transmitter can be switched as a receiver at will, define working mode freely, fulfill multiple use cases.

Innovation OLED Screen Design
Reading status and control system easily
The W1000H has a creative OLED screen so you can check out all device status and control the system with displayed information on the screen.

1080P HD Image Quality
The resolution supports 1080P60,1080i60 and under 1080P60 format, provide a higher quality image.

One Transmitter to Multiple Receivers
Monitoring for everyone on set
More than one device can “join the party”. W1000H allows you have up to four receivers bound to one transmitter that efficient your crew monitor every shot as it happens.

13 Frequency Channels, AUTO Scan
Make the shooting screen more stable
There are 13 frequency channels. Automatically scan the current environment to find out available channels and avoid the channels with interference.

Scene Modes, Switch Freely
Each channel can choose image quality priority or latency priority, switch freely as needed to help you easily cope with different occasions.

Built-in Fan, Effective Cooling
The excellent cooling design enable the device working long time in hot environment as well.

Real-Time APP Monitoring , Support Android/iOS system
Supports both Android and IOS system APP monitoring, up to 4 phones or tablets real-time monitoring with professional monitor features, such as monochrome, false color and center mark(other features are under development).

IOS users can search “ feelworld” on APP store to get APP (name: MMonitor)

Android APP (name: Feelworld Wireless ) can be get from the following ways: .
1. search “feelworld wireless”in GOOGLE PLAY
2. scan the QR code

Multiple Power Options , Long-lasting power for your shooting
The W1000H is equipped with Sony F970 battery plate to be powered by standard F970 battery (Sold separately) , Type-C ( 5V/1.5A ) charging and 6-16V DC power options.
Note: Due to the actual output of some batteries will be greater than 16V, which may burn the machine. Please ensure that the actual output voltage of the battery used is less than 16V.

Wide Range Application
The W1000H is widely used in the areas of filmmaking, sports events, wedding live broadcast, church live streaming, corporate events etc.



 SPECIFICATION

Transmitter

 Screen  OLED
 Interface

 1 * HDMI input

 1* HDMI output

 2 *Antenna port (RP-SMA Male)

 DC power input

 3.5mm headphone jack

 Type-C

 Power Supply Way/Voltage

 F970 battery

 Type-C: 5V/1.5A

 DC adapter: 6-16V

 Power Consumption  <7.5W
 HDMI Format

 480P60, 576P60

 720P60/59.94/50

 1080P60/59.94/50/30/29.97/25/24/23.98

 1080I60/59.94/50

 HDMI Type A

 Frequency  5.1-5.9GHz
 Modulation Mode  OFDM
 Transmission Power  Maximum 17dBm
 Band Width  20MHZ
 Occupied Bandwidth  20/40MHz
 Latency  Min 0.08S
 Intercom Frequency Response Range  20Hz~20KHz
 Operating Temperature  0℃ ~ 40℃
 Storage Temperature  -20℃ ~ 60℃
 Unit Size(mm)  67L*24W*118H (excluding antenna)
 Unit Weight  128g



Receiver

Screen  OLED
 Interface

 2* HDMI output

 2 *Antenna port (RP-SMA Male)

 DC power input

 3.5mm headphone jack

 Type-C

 Power Supply Way/Voltage

 F970 battery

 Type-C: 5V/1.5A

 DC adapter: 6-16V

 Power Consumption  <6.5W
 HDMI Format  480P60, 576P60

 720P60/59.94/50

 1080P60/59.94/50/30/29.97/25/24/23.98

 1080I60/59.94/50

 HDMI Type A

 Frequency  5.1-5.9GHz
 Modulation Mode  OFDM
 Receiving Sensitivity  -87dBm
 Band Width  20MHZ
 Occupied Bandwidth  20/40MHz
 Latency  Min 0.08S
 Intercom Frequency Response Range  20Hz~20KHz
 Operating Temperature  0℃ ~ 40℃
 Storage Temperature  -20℃ ~ 60℃
 Unit Size(mm)  67L*24W*118H (excluding antenna)
 Unit Weight  128g



PACKAGE INCLUDES

  • 1 × Transmitter
  • 1 × Receiver
  • 5 × Antenna
  • 1 × Cold Shoe
  • 1 × Type-C to USB Adapter
  • 1 × User Manaul
